Telcon HTP50NPVA 产品图片

Telcon HTP50NPVA

  • 型号 HTP50NPVA
  • 订货号HTP50NPVA
  • 品名Power Supply Module
  • 品牌Telcon
  • 产地英国
  • 货期请咨询
友情提示：本公司并非Telcon 官方代理商

器件邦采购顾问

销售经理:张经理
手机：17628601703
微信：euromro
邮箱：315689107@qq.com

产品介绍

  • 型号HTP50NPVA
  • 订货号HTP50NPVA
  • 品名Power Supply Module
  • 品牌Telcon
  • 描述HTP50NPVA HTP50NPVA Power Supply Module属于Telcon ，产地为英国
  • 产地英国
  • 单位台
  • 净重-- kg
  • 毛重-- kg
  • 海关编码--
  • 本站编号79P249626

Telcon HTP50NPVA Power Supply Module
The HTP25NP is a closed loop Hall Effect Current Transformer suitable for measuring currents up to 25A. The product provides an output current, galvanically isolated from the primary conductor into an external load resistance. All contacts, including the primary are designed for PCB mounting.

* High Accuracy

* 2.5 kV Proof Stress

* Fast Response

* All Contacts via PCB

* Designed in Quality Applications

* Variable Speed Drives

* UPS Systems

* D.C. Power Supplies

* Low Frequency Current Measurement Benefits
Nominal Primary Current Turns Ratio Nominal Power Supply   Power Supply Current   Minimum Load Resistance Operating Temperature Range Storage Temperature Range 25A 1000:1     ±15V ±5% 14mA per rail + output current 100 Ù   0 to +70°C -25°C to +85°C SPECIFICATION   Linearity   Limit of Linearity   Overall Accuracy Output Offset Current Output Offset Current After Overload Zero Offset/Temperature Zero Offset/Supply Variation Coil resistance Bandwidth (-1dB) di/dt following Delay Time   dV/dt Immunity Proof Stress Voltage 0.1% of nominal primary current. ± 36A peak value 0.5% of nominal primary current <±100µA at primary current =0A <±250µA at primary current =0A <5µA/°C   <5µA/V 52 Ù   dc to 150kHz min. >100A/µs 0.1µS 10kV/µs 2.5kV a.c., rms, 50Hz for 1 minute, Primary pins to output terminals
